Fadal 3016 FXMP (2009)

× Bidding has ended on this item.
Ended
TIMED AUCTION

21 ATC, Cat 40 Spindle Taper, 39″ x 16″ Table Size

Prev Lot
  Lot # 1
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Illinois
  • Logistics
    THERE WILL BE A LOADING COST OF $750.00 AND WILL BE AUTOMATICALLY INCLUDED ON THE SALES INVOICE.

  • Lot # 1
  • System ID # 564668
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 564669
Description

X-Axis Travel 30"

Y-Axis Travel 16"

Z-Axis Travel 20"

Table Size 39" x 16"

Maximum Weight on Table 2,736 Lbs

Spindle Nose to Table 4" to 24"

Spindle Center to Column Ways 16"

Spindle Speeds 10 to 10,000 RPM

Spindle Motor 15 HP

Spindle Taper Cat 40

ATC, Number of Tools 21

No. of Ground Boxways per Axis (X/Y/Z) 2

Machine Size: 98" W x 77" D x 103" H

Machine Weight: 8.550 Lbs
