Okuma 2SP-35HG Front facing Lathe 2006

× Bidding has ended on this item.
Ended

(2) 10" Kitagawa Chucks, Loaded/Unloaded Gantry System, Chip Conveyor

  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Indiana
  • Logistics
    THERE WILL BE A LOADING COST OF $1,250.00 AND WILL BE AUTOMATICALLY INCLUDED ON THE SALES INVOICE.

  • Lot # 1
  • System ID # 560000
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 560001
Description

Distance Between Centers: 17.72"
Max Turning Diameter: 11.02"
Max turning length: 9.06"
Spindle Nose: A2-8
Spindle Diameter: 4.72"
Chuck size 10"
Hole-Thru-Spindle Dia: 3.23"
Spindle speed: 35 RPM to 3500 RPM
No of tools per turret: 12 + 12
X-Axis travel: 8.86"
Z-axis Travel - 9.06"
Floor Space Requirement: 114.17" x 94.88"
Overall height: 87"
Approx. Weight: 22,000 lbsx 70"
Weight: 5,700 Lbs.



Equipped With:

Fanuc 18iT Control
(2) 10" Kitagawa Chucks
One Loaded/Unloaded Gantry System
Chip Conveyor
Coolant System



Shipping Dimensions
Machine: 17’l x 9.5’ W x 10.5’h - 23k lbs.
Work stocker: 13’l X 4.5’w X 5’h – 5k lbs.
