Lagun Lagunmatic 250 CNC Vertical Mill

× Bidding has ended on this item.
Ended

3-Axis, Vickers CNC Control (G-Code), Remote Pendent

Prev Lot
  Lot # 3
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Loveland, CO
  • Logistics
    Prep and loading is the responsibility of the buyer.

  • Lot # 3
  • System ID # 551950
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 551951
Description

Control: Vickers

Table Working Surface  10"x 44"

Table Size 16" x 48"

Table Load Capacity 1000 LBS

Longitudinal Travel (X-Axis) 27"

Cross Travel (Y-Axis) 15"

Vertical Travel (Z-Axis) Spindle 6.5"

Vertical Travel (Z-Axis) Knee (Manual) 16"

Maximum Clearance Table Top to Spindle Nose 18.25"

Spindle Taper 40

Spindle Motor  3 HP

Feed Rates, All Axes 0.1 to 250 IPM

Rapid Traverse Rate, All Axes  350 IPM

Spindle Speeds Range  60-4250 RPM

Approximate Machine Dimensions 5ft L x 4ft W x 9ft H

Approximate Machine Height 99"

Approximate Machine Weight  4,500 Lbs.

Table Working Surface 10"x 44"

Table Size 16" x 48"

Table Load Capacity 1000 LBS

Longitudinal Travel (X-Axis)  27"

Cross Travel (Y-Axis) 15"

Vertical Travel (Z-Axis) Spindle 6.5"

Vertical Travel (Z-Axis) Knee (Manual) 16"

Maximum Clearance Table Top to Spindle Nose 18.25"

Spindle Taper  40

Spindle Motor  3 HP

Feed Rates, All Axes 0.1 to 250 IPM

Rapid Traverse Rate, All Axes 350 IPM

Spindle Speeds Range 60-4250 RPM

Approximate Machine Dimensions 5ft L x 4ft W x 9ft H

Approximate Machine Height  99"

Approximate Machine Weight 4,500 Lbs.

Electrical 240V, 3PH, 60HZ



Equipped With:

3-Axis Vickers CNC Control( G-Code)

Remote Pendent

Bjur Lubrication System
