LOT 24

South bend Johnson G21507236

Current Price
$100.00
No Reserve ? $100.00
Remaining Time 40 Days, 20:01:14
Your Maximum Bid: $0.00
Machine Tool Bids will bid incrementally for you up to your maximum bid. Your maximum bid is kept a secret from other users.
Your bid is a contract between you and the listing creator. If you have the highest bid you will enter into a legally binding purchase with 18% buyer premium contract.
Machine Details
Location: Juarez, Mexico
Lot #: 24
End Date: Wednesday, October 21, 2026 12:20 PM
Start Date: Thursday, September 10, 2026 11:00 AM
Item #: 5359904
Machine Description

South bend Johnson G21507236



Description

150 ton, two point/double crank, gap frame mechanical stamping press with 72 in. left to right × 36 in. front to back T slotted bed; floor standing construction; air clutch and brake; air counterbalanced slide; powered slide adjustment; automatic lubrication; dual palm button operator controls; forward, reverse, inch, single stroke and continuous operating modes. Equipped with press control cabinet, light curtain guarding, die area guarding and CWP coil feed equipment. 1CWP model 4R-24 single-end pull-off coil reel: 6,500-lb. maximum coil weight, 24-in. maximum stock width, 60-in. maximum coil OD, 13–17-in. standard mandrel expansion range plus removable pads for 17–21 in. coil ID, right to left payout direction, manual mandrel expansion, pneumatic spindle brake requiring 80–100 PSI. CWP model 12B powered stock straightener: 12 in. maximum stock width, 0.018–0.125 in. mild steel thickness range, 120 thru 600 IPM operating range, right to left material flow, 80–100 PSI air requirement, 440V/3 phase/60 Hz electrical supply, 8 full load amps; equipped with powered straightening rolls, pneumatic pinch roll adjustment, entry/exit stock support rollers and forward/reverse/jog controls. Also includes AutomationDirect touchscreen T002 servo feeder control cabinet, press mounted electronic servo roll feeder, stock loop control sensor on floor stand, dual palm button press control console, light curtain guarding on both sides of the die area, interlocked perimeter guarding, expanded metal service platforms and steps, pneumatic equipment, press lubrication system and associated electrical control cabinets.
