Smart SM-1000 2017 Vertical Machining Center

× Bidding has ended on this item.
Ended

47.25" x 20.07" Table, Renishaw Probe Receiver, 12000 RPM Spindle w/ CAT40 Taper

  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Wichita. KS
  • Logistics
    THERE WILL BE A LOADING COST OF $950.00 AND WILL BE AUTOMATICALLY INCLUDED ON THE SALES INVOICE. ALL EQUIPMENT MUST BE REMOVED BY END OF DAY 6/29/22 - NO EXCEPTIONS.

  • Lot # 11
  • System ID # 534535
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 534536
Description

Control:Fanuc 0i-MF Control

X axis travel 40.15”
Y axis travel 20.07”
Z axis travel 20.07”
Table size 20.07” x 47.24”
Table loading capacity 1,503 lbs.
Distance from table top to spindle nose 3.93” – 24.01”
Distance from column to spindle center 23.62”
Spindle taper CAT40 (BIG PLUS)
Spindle speed 12,000 rpm
AC Spindle motor 25 hp
Spindle Torque (30 min) 70 ft.-lbs.
Magazine capacity 24
Tool shank CAT40
Rapid traverse ( X / Y / Z ) 1,259 ipm/1,259 ipm/945 ipm
Cutting federate ipm 590 ipm
Slide Ways Cross Roller Linear Way
Floor space ( L x W x H ) 138.2 x 87.6 x 116.5
CNC Model Fanuc 0i-MF



Equipped With:

Lift Up Auger
Renishaw Probe ready receiver and software
Coolant thru-spindle preparation
Coolant and Air Gun
3 Color Tower Light
i-Handle Remote

Work Lights



*MACHINE HAS ONLY CUT ALUMINUM*
