Smart VX 350-5AX 2019 (5) 5-Axis Plus Machining Center

× Bidding has ended on this item.
Ended

Trunnion Table w/ 4th & 5th Axis, Renishaw OM Kit (Prepped Only), CAT40 Big Plus

Prev Lot
  Lot # 10
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Wichita. KS
  • Logistics
    THERE WILL BE A LOADING COST OF $950.00 AND WILL BE AUTOMATICALLY INCLUDED ON THE SALES INVOICE. ALL EQUIPMENT MUST BE REMOVED BY END OF DAY 6/29/22 - NO EXCEPTIONS.

  • Lot # 10
  • System ID # 532771
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 532772
Description

Control:  Fanuc 0i-MF

X-Axis Travel: 27.55"
Y-axis Travel: 17.71"
Z-axis travel: 16.53"
A-axis travel: + 30/-120 degrees
C-axis Travel: 360 degrees
Table size: 13.77" (diameter)
Spindle Taper: CAT 40 (Big Plus)
Spindle speed: 12,000 RPM
Spindle HP: 15HP
ATC Capacity: 32
spindle to table top: 22.44"
rapid traverse rate: 1,890 IPM



Equipped With:

Built-in tilting trunnion with 4th and 5th axis tilt
Coolant Thru Spindle (300 PSI)
Fully enclosed splash guards with top and ATC cover
Renishaw OMI-2T (Prep only)
Oil skimmer
Chip Conveyor
Spindle Chiller
Splash Gun

Remote MPG



*MACHINE HAS ONLY CUT ALUMINUM*
