SWING OVER BED 11"

SWING OVER CARRIAGE 9"

SWING OVER CROSS SLIDE 6"

DISTANCE BETWEEN CENTERS 18"

SPINDLE THROUGH HOLE 1.25"

SPINDLE NOSE HARDINGE TAPER

SPINDLE SPEED 125- 3,000 RPM

MAX COLLET CAPACITY 1.0625"

COMPOUND SLIDE TRAVEL 3"

POWER FEED RANGE 0.25" - 7" IPM

TAILSTOCK TRAVEL 3.75"

TAPER IN TAILSTOCK #2 MORSE

(27) THREADS 11 - 108 TPI

MAIN MOTOR 1.56 HP / 3 PHASE / 50 CYCLE / 400 / 440V

Motor: 1.5 Hp, 220v, 3ph

APPROX MACHINE DIMENSIONS 72" X 30" X 65"

Equipped With:

Inch Threading

Tailstock

Tool Post, Misc. Tool holders

ALL EQUIPMENT MUST BE REMOVED BY MAY 27TH.  ANY EQUIPMENT STILL AT THE FACILITY AFTER MAY 27TH WILL BE CONSIDERED ABANDONED AND SCRAPPED
