Okamoto ACC-12/24DXWCP Surface Grinder 1998

× Bidding has ended on this item.
Ended

7.5 HP Grinding Wheel Spindle, 12"x24" Table Working Capacity

Prev Lot
  Lot # 6
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
  • Location
    Illinois
  • Logistics
    A LOADING FEE OF $800.00 WILL BE ADDED TO THE WINNING BIDDER'S INVOICE. THIS LOADING FEE IS NON-NEGOTIABLE AND COVERS LOADING OF THE MACHINE ONTO BUYER ARRANGED TRUCK. CONTAINERS CAN NOT AND WILL NOT BE LOADED ON-SITE

  • Lot # 6
  • System ID # 469493
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 469494
Description

Year 1998

Control: FANUC Series O-M

Table Working Capacity: 12"x24"

Maximum Distance under 12" Wheel to Table Surface: 13.6"

Table Load Capacity: 925lbs.

T-Slots: 0.7"x3 (WidthxNo.)

Longitudinal Feed (X Axis)

Maximum Table Travel: 30"

Table Feed Rate: 3-82 ft/min.

Feed per Handwheel Revolution: 1.85"

Crossfeed (Z Axis)

Maximum Saddle Travel: 13.3"

Intermittent Traverse Feed: 0.02-0.80 inch/min.

Grinding Feed: 0.001-40.0 inch/min.

Rapid Feed: 40.0 inch/min.

Jog Feed: 0-40.0 inch/min.

Manual Pulse Generator: 0.00001, 0.0001, 0.001 inch

Vertical Feed (Y Axis)

Grinding Feed: 0.001-40.0 inch/min.

Rapid Feed: 40.0 inch/min.

Jog Feed: 0-40.0 inch/min.

Manual Pulse Generator: 0.00001, 0.0001, 0.001 inch



ALL EQUIPMENT MUST BE REMOVED ON APRIL 30TH.  ANY EQUIPMENT STILL AT THE FACILITY AFTER APRIL 30TH WILL BE CONSIDERED ABANDONED AND SCRAPPED.
