Mitsubishi M-H4B/16 Horizontal Machining Center (2000)

× Bidding has ended on this item.
Ended
TIMED AUCTION
Prev Lot
  Lot # 16
Next Lot
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Tennessee
Logistics
BUYER RESPONSIBLE FOR LOADING AND FREIGHT

  • Lot # 16
  • System ID # 4691983
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 4691984
Description

Mitsubishi M-H4B/16 Horizontal Machining Center (2000)



Description


Pallet Size (Cap.) 15.75″ x 15.75” / (880 lbs.)
Pallet Indexing (B-Axis) 0.001°
Spindle Nose to Table Center 5.9″ – 31.5″
Spindle Center to Tabletop 2″ – 24″
X-Axis Travel 25.6″
Y-Axis Travel 25.6″
Z-Axis Travel 25.6″
Spindle Taper CT – 40
Spindle Speed 12,000 rpm
Spindle Motor 30 hp.
Tool Changer Capacity: 60 Stations
Rapid Traverse Rates 1,575 ipm
Tool Change Time (T-T / C-C) 1.3 / 3.8 Secs.
Maximum Tool Diameter / Weight / Length 5.9″ / 11.8” / 18 lbs.
Electrical Requirements 230V/3Ph/60Hz
Machine Dimensions 17’L x 11’W x 10’H
Machine Weight 23,150 lbs.



Equipped With

Chip Conveyor,
Fanuc 18i-M Control,
Probing,
Coolant Thru Spindle
