Knuth FSM 480 Surface Grinder (2024)

Description

WORKING AREA
Table dimensions: 8 in x 18 in
Spindle axis-to-table surface distance: 17.72 in

TRAVELS
Travel X-axis: 18.9 in
Travel Y-axis: 9 in
Travel distance per hand- wheel rotation, X-axis: 0.2 in
Travel distance per hand-wheel rotation, Y-axis: 0.2 in
Travel distance per hand-wheel rotation, Z-axis: 0.04 in

FEED
Scale ring division X-axis: 0.00079 in
Scale ring division Y-axis: 0.00079 in
Scale ring division Z-axis: 0.0002 in

ACCURACIES
Roughness: >=063 μm Ra

Power Requirements:
230v/60hz/3ph

Equipped With

Exhaust vacuum,

Work lamp,

Magnetic clamping plate 5"x11.75",

Balancing shaft,

Balancing station,

Angle - adjustable grinding vise,

Grinding wheel flange,

Grinding wheel dresser,

Grinding wheel,

Operating tools,

Operator manual
