Emco Turn 332MC Horizontal Turning Machine (2003)

Description

Bar Capacity - 1.25"
Max Swing Over Slant Bed - 16"
Max Turning Capacity - 8.7"
Max Machinable Center Distance - 20"
Cross Travel (X-Axis) Upper Turret - 6.3"
Lower Turret - 5.5"
Longitudinal Travel (Z-Axis) Upper Turret - 20.1"
Lower Turret - 20.1"
C-Axis on Both Spindles - .001 Degree
Tool Positions (12 on Each Turret) - 24 Total
Spindle Nose - A2-4
Spindle Speed Range - 50-8000 RPM
Spindle Horsepower - 17 HP
Counter Spindle - 7000 RPM
Counter Spindle Horsepower - 13 HP
Live Tooling Speed Range - 98-6000 RPM
Live Tooling Horsepower - 6.8 HP
Approximate Machine Dimensions - 78" x 104"
Approximate Machine Height - 78"
Approximate Machine Weight - 6700 LBS

Equipped With


Coolant Tank,
Chip Conveyor,
Parts Conveyor,
(2) Collets,
Static Tooling,
Live Tooling,

Overall, the machine is in good running condition. Low hours for the age... The turrets were both rebuilt in the last 5 years and are in great operating shape. The 3 transformers have all been replaced in the last 2 years of operation. It currently has a PLC fault relating to the ER Module.
