Doosan Puma TT1800SY CNC Multi-Axis Lathe (2006)



Bar Capacity: 2.625"
Chuck Size: 8"
Spindle Speed: 5,000 RPM
Spindle Motor: 30 HP
X Axis Travel: 6.5"
X2 Axis Travels: 7.5"
Z Axis Travel: 31.5"
Z2 Axis Travels: 28.3"
Y Axis Travel: 3.9"
A Axis Travel: 30.3"
Rapid Rate Z Axis: 944 IPM
Rapid Rate X Axis: 787 IPM
Max Turning Dia: 9.1"
Max Turning Length: 9.1"
Max Swing: 9.1"

TURRETS:
Size: BMT45
Turret Configuration (Upper + Lower): 24 + 24 (48 Total Stations)
O.D Tool Size: 0.8" x 0.8"
Maximum I.D. Tool Size: 1.3"
Turret Indexing Time: 0.15 Seconds
Maximum Rotary Tool Speed: 5,000 RPM

SUB & MAIN SPINDLE:
Spindle Speed: 5000 RPM
Spindle Motor (30 min / Cont): 29.5 HP / 20.1 HP
Maximum Spindle Torque: 153.5 Ft-Lbs
Spindle Nose: A2 #6
Spindle Bearing Diameter: 4.3"
Spindle Inner Diameter: 3.0"
C-Axis Indexing: 360° in .001° increments

Dimensions: 154" x 81" x 82"
Weight: 19,400 LBS





Equipped With



Fanuc Control
LNS Quick Load Servo S3 Bar Feeder
Chip Conveyor
C- Axis
TOOL INCLUDED,
Qty. 1 pcs. Double side turn tool main/sub
Qty. 4 pcs. Triple station 1” bore block
Qty. 5 pcs. Single station 1-1/4” bore block
Qty. 5 pcs. Single station 1-1/2” bore block
Qty. 6 pcs. Live cross block
Qty. 5 pcs. Live face block
Qty. 3 pcs. Standard 1.0” turn block
Qty. 2 pcs. Double ½ station ¾” turn block
Qty. 3 pcs. Rear set 1-1/2” bore block
