Okamoto ACC-1224DXNCP Surface Grinder (2004)

× Bidding has ended on this item.
Ended
TIMED AUCTION
Prev Lot
  Lot # 3
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Anaheim, CA
Logistics
BUYER RESPONSIBLE FOR LOADING AND FREIGHT

  • Lot # 3
  • System ID # 3558489
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 3558490
Description

Okamoto ACC-1224DXNCP Surface Grinder (2004)



Table Capacity: 12″x24″
Maximum Distance Under 12″ Wheel to Table Surface: 13.6″
Table Load Capacity: 925 LBS
T-Slots: 0.7″ x 3

Maximum Table Travel: 30″
Table Feed Rate: 3-82 ft/min
Feed Per Handwheel Revolution: 1.85″

Maximum Saddle Travel: 13.3″
Intermittent Traverse Feed: 0.02 – 0.80 inch/min
Grinding Feed: 0.001 – 40.0 inch/min
Rapid Feed: 40.0 inch/min
Jog Feed: 0-40.0 inch/min
Manual Pulse Generator: 0.00001, 0.0001, 0.001″

Grinding Wheel Size: 12″x1.5″x5″
Speed: 500 – 1,800 RPM

Grinding Wheel Spindle Motor: 7.5 HP
Crossfeed AC Servo Motor: 0.7 HP
Vertical Feed AC Servo Motor: 0.7 HP
Hydraulic Pump Motor: 2.0 HP




Equipped With:



Fanuc OM Control

Wheel Adapter

Automatic Lubrication System

Full Table Enclosure

Table Back Guard

Splash Cover with Coolant Nozzle

Oil Cooled Wheelhead

Hydraulic Oil Temperature Regulator

Conversational Form Programming System

Built-in Chuck Control



Floor Space: 107″ x 79″ x 95″
Weight: 6,175 LBS
