Tung-Yu TYC-V-16-A-2-S-PCD (2019)

× Bidding has ended on this item.
Ended
TIMED AUCTION

250T Clamping Force, 19.68" Stroke, 23.62" Daylight, Hydraulic Cylinder

Prev Lot
  Lot # 1
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Lexington, SC
Logistics
There will be a loading cost of $1,200.00 and will be automatically included on the sales invoice. Removal: Riggers will be on site 7/23-7/25 for removal

  • Lot # 1
  • System ID # 2987688
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 2987689
Description

Tung-Yu TYC-V-16-A-2-S-PCD 250 T Transfer Injection Type Compression Molding Machine, built in 2019



Clamping Force: 250 T

Working Pressure (MAX): 210 Kg/cm2 or 2,986 PSI

Piston Diameter: 400mm or 15.7"

Stroke (Max): 500mm or 19.68"

Daylight (Max): 600mm or 23.62"

Heater Capacity: 18.3 KW X2

Heating Platen Dimension: 570 x 610 mm or 22.44" x 24.01"

Oil Reservoir: 600L or 158 gallons

Main HP: 15 HP x 6 HP

Vacuum Horsepower: RA-0202D

Way of Mold In/Out: Hydraulic Cylinder

Available Stroke of Vacuum Cover Cylinder 450mm = 17.71"

Service Thickness of Mold: 280 ~ 380 mm or 11" x 14.96"
