Doosan Lynx 220C CNC Lathe (2008)

× Bidding has ended on this item.
Ended
TIMED AUCTION

12 Station Turret, ​​​8" 3-Jaw Hyd Chuck, Toolpresetter

Prev Lot
  Lot # 28
Next Lot
Listing Image
  • Starting Bid: $100.00
  • 0 Bid(s)
View Seller's Other Listings
Details
Location
CENTREPORT, MB, CANADA
Logistics
BUYER RESPONSIBLE FOR LOADING AND FREIGHT/ rigger is scheduled for 3/15.
  • Lot # 28
  • System ID # 2709787
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 2709788
Description

Doosan Lynx 220C CNC Lathe (2008)



Capacity:
Max Turning Diameter : 12.6″
Max Swing Over Bed : 20.1″
Max Swing Over Saddle : 11.4″
Max Turning Length: 12.0″
Max Bar Capacity : 2.6″

Travels:
X Axis Travel : 6.9″
Z1 Axis Travel : 13.0″
Rapid Traverse X Axis: 1181 IPM
Rapid Traverse Z Axis: 1417 IPM

Spindle:
Spindle Nose: A2-6
Spindle Bore: 3.0″
Spindle Speed: 4000 RPM
Spindle Motor: 20 HP

Turret:
Turret Capacity: 12 Stations
Turret Index Time: 0.11 Second

General:
Power Source: AC 220v / 3-Phase / 60 Hz
Power Requirement: 23.68 kva




Equipped with:


8" 3-Jaw Hydraulic Chuck
12 Station Turret
Tool Presetter
USB Drive
PCMCIA Card Slot
Coolant System
Chip Conveyor
Foot Switch
Fanuc i Control



Machine Dimensions: 91.5″ x 63″ x 65″ High
Machine Weight: 7,716 lbs Approx.
