Mori-Seiki SL-154SMC CNC Lathe (2003)

× Bidding has ended on this item.
Ended
TIMED AUCTION

6" 3-Jaw Chuck, Chip Conveyor, (5) Live Tool Holders

Prev Lot
  Lot # 11
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Denton, Texas
Logistics
Loading fee of $750 will be added to winning invoice

  • Lot # 11
  • System ID # 2507124
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 2507125
Description

Mori-Seiki SL-154SMC CNC Lathe (2003)


Chuck Size 6"
Max Diameter Bar Capacity 1.7"
Max Swing Over Bed / Carriage 26.8" / 17.9"
Max Turning Diameter / Std 16.9" / 6.6"
Max Machining Length 13.7"
Distance Between Centers 24.8"
Spindle Motor 10 / 7.5 HP
Spindle Speed 60 - 6000 RPM
Spindle Bore 2.2"
Spindle Nose A2-5
Tools 12 (All Live)
Rapid Traverse Rates (X / Z) 708 / 945 IPM
X-Axis Travel 9.1"
Z-Axis Travel 20.5"
C-Axis Index .001 Degree
Milling Motor 3.5 HP
Milling Speed 3000 RPM
Sub Spindle Motor 10 / 7.5 HP
Sub Spindle Bar Capacity 1.3"
Turret Index (Single Step) 0.2 Seconds

Equipped With:
6" 3-Jaw Chuck
Chip Conveyor
(5) Live Tool Holders
Various Static Tool Holders
Part Catcher
13,000 Cutting Hours Approx.

Machine Dimensions (L x W x H) 91.3" x 73.7" x 72.5"
Machine Weight 9020 lbs.
