Machine Details
Location: Pomona, California
Logistics: Buyer is responsible to decommission the machine in addition to to being responsible for loading and freight.
Lot #: 35
End Date: Wednesday, August 30, 2023 6:50 PM Central Standard Time
Start Date: Thursday, July 20, 2023 5:00 PM Central Standard Time
Item #: 2119853
Machine Description

Trumpf Tubematic Tube Laser (2004)


Max Laser Output: 3200 Watts
Max Tube Length: 6500 mm (255")
Min Tube Diameter: 20 mm (.78")
Max Tube Diameter: 150 mm (5.9")
Max Work Piece Weight (raw material): 120 kg
Max Tube Bundle Weight: 4000 kg
X Axis Speed: 1000 m/min
Y Axis Speed: 40 m/min
Z Axis Speed: 40 m/min
A Axis Speed: 720 degrees/sec
Positioning Accuracy: +/- 0.2 mm
Repeatability: +/- 0.06 mm
Electrical Supply: 460V, 3-Phase, 60Hz
Connected Load: 72kVA
Full Load Current: 104A
AMP rating of largest motor: 13A
Necessary Fuse Protection: 3x 125A


Equipped With:
Siemens Sinumerik 840D CNC Control
TLF 3200 Laser Resonator
Auto Load System
Chiller
