Machine Details
Location: Owatonna, Minnesota
Logistics: Loading fee of $500.00 will be added to the winning invoice.
Lot #: 23
End Date: Wednesday, August 30, 2023 5:50 PM Central Standard Time
Start Date: Thursday, July 20, 2023 5:00 PM Central Standard Time
Item #: 2115093
Machine Description

Hishinuma CX 25 Hot Chamber Die Cast Machine (2001)


Locking Force: 28 tons
Space Between Bars: 10.6" x 10.6"
Die Stroke: 6.1"
Die Thickness min-max): 5.5" - 13"
Ejection force: 2 tons
Ejection Stroke: 1.97"
Shot force: 3.6 tons
Shot stroke: 5.12"
Shot position: 0 & -1.57"
Plunger Diameter: 1.77"
Metal Pressure: 2,930 psi
Maximum castable area: 18 sq in
Maximum shot weight: 1.76 lbs/zinc
Motor Size: 7hp


Equipped With:
Standard features:

Hydraulic nozzle break
Hydraulic ejector
Automatic central lubrication for toggles
Motorized die height
Toggle Guards
Omron PLC
Electric Heat for nozzle
Electric Heat for goosneck
Temperature control for gas furnace
Hydraulic core pull circuit
Meets U.S. safety specification
Instruction/maintenance manual


Additional Options:
Hydraulic system for shot position adjustment
Model MSR-500 extractor
Model MCH-Jr auto sprayer



Overall Dimensions: 117 x 50 x 67"
Machine Weight: 3.3 tons
