Haas VF-2 Vertical Machining Center

× Bidding has ended on this item.
Ended
TIMED AUCTION

36" x 14" Table, 7,500 RPM, 21 ATC Tool Changer

Prev Lot
  Lot # 21
Next Lot
Listing Image
  • Starting Bid: $100.00
  • 0 Bid(s)
Details
Location
Auburn, Washington
Logistics
Loading fee of $600.00 will be added to the winning invoice.

  • Lot # 21
  • System ID # 2113582
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 2113583
Description

Haas - VF-2 Vertical Machining Center (1994)


X Axis Travel: 30″
Y Axis Travel: 16″
Z Axis Travel: 20″
Rapid Rate X Axis: 1,000 IPM
Rapid Rate Y Axis: 1,000 IPM
Rapid Rate Z Axis: 1,000 IPM
Table Size: 36″ x 14″
Max Table Load: 3,000 LBS
Spindle Motor: 20 HP
Spindle Speed: 7,500 RPM
Spindle Taper: 40 CT
Tool Changer: 21 ATC
Max Torque: 90 ft-lbf
Max Thrust X: 2550 lbf
Max Thrust Y: 2550 lbf
Max Thrust Z: 4200 lbf
Max Tool Diameter 3.5″
Max Tool Weight 12 lb.


Dimensions: 101″ x 99″ x 101″
Weight: 7,800 LBS
