LeBlond NK 40X108 Engine Lathe

× Bidding has ended on this item.
Ended
TIMED AUCTION

36" Chuck, Faceplate, Tailstock, Ways Reground & Rescraped

Prev Lot
  Lot # 6
Next Lot
Listing Image
  • Starting Bid: $100.00
  • 0 Bid(s)
Details
Location
Mesa, Arizona
Logistics
Loading fee of $700.00 will be added to the winning invoice.

  • Lot # 6
  • System ID # 2030554
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 2030555
Description

LeBlond NK 40X108 Engine Lathe


SWING OVER BED: 40.00 in. 1016.00
SWING OVER CROSSLIOE: 25.00 in. 635.00
DISTANCE BETWEEN CENTERS: 114.00 in. 2895.60
X • CROSSLIDE TRAVEL: 24.00 in. 609.60
Z • CARRIAGE TRAVEL: 106.00 in. 2692.40
CHUCK DIAMETER: 36 in (915 mm)
CHUCK TYPE: FACEPLATE WITH 4 INDEPENDENT JAWS
SPINDLE BORE: 3.00 in. 76.20
SPINDLE POWER: 40 HP
SPINDLE SPEED: 3- 400 RPM
TAILSTOCK QUILL DIAMETER: 8"
TAILSTOCK QUILL TRAVEL: 18"
WAYS: HARDENED REPLACEABLE
POWER 3PHASE / 50-60 Hz/ 200 • 500 Volts: existing

Equipped With:
36" Chuck
Faceplate
Tailstock


SPECIAL FEATURES OR ADDITIONAL ITEMS:
BUILT IN LIVE CENTER IN TAILSTOCK, BALL
SCREW ON CROSS SLIDE


MACHINE DIMENSIONS
Length: 250" x Width:100" 79" Height:
WEIGHT: 35000 lbs


CONDITION: EXCELLENT-WAYS REGROUND AND RESCRAPED 2010
