Makino A55 CNC Horizontal Machining Center

× Bidding has ended on this item.
Ended
LIVE WEBCAST

4 Sided Hydraulic Tombstone, 40 ATC, Chip Conveyor, Coolant System

  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Ponce, Puerto Rico

  • Lot # 51
  • System ID # 1999165
  • Item # 1999166
Description

Makino A55 CNC Horizontal Machining Center (1995)

S/N: A95-774-199511
New 11/1995

Pallet Size (Millimeters) 400
Pallet Size 16" x 16"
X-Axis Travel: 22"
Y-Axis Travel: 22"
Z-Axis Travel: 22"
40 ATC
Spindle Speed: 12,000 RPM
Spindle Taper: #40
Control Makino Pro 3
Pallet Indexing: Full 4th Axis
Spindle Motor:30/25 HP

Equipped with:
4 Sided Hydraulic Tombstone
Spindle Chiller
Toolholders
Chip Conveyor
Coolant Through-Spindle Coolant

Main Unit Dimensions (in inches): Length: 104.00" Width: 146.00" Height: 111.50"

Components: Chip Con / Coolant System: Length: 130.00" Width: 60.00" Height: 60.00"

CTS Filter/Pump: Length: 22.00" Width: 44.00" Height: 76.00"
