Charmilles Roboform 55 CNC Sinker EDM (2001)

× Bidding has ended on this item.
Ended
LIVE WEBCAST

100RPM C-Axis, 29.5" x 19.6" Clamp Area, Cascade Tank Door

Prev Lot
  Lot # 37
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Ponce, Puerto Rico

  • Lot # 37
  • System ID # 1998668
  • Item # 1998669
Description

Charmilles Roboform 55 CNC Sinker EDM (2001)

S/N: 665146

X-Axis Travel: 23.62"
Y-Axis Travel: 15.7"
Z-Axis Travel: 17.7"
Max Workpiece Weight: 3500lbs
Max Electrode Weight: 110lbs
C-Axis Rotation Speed: 100 RPM
Clamp Area: 29.5" x 19.6"
Max. distance between the table surface & base of - the electrode holder (approx.) 23.1"
Min. distance between chuck & table (approx.) 5.9"
Work Tank: Max. dielectric level 17.32"
Dielectric System: Fill pump flow 83 US gpm
Dielectric reservoir capacity 192 US gal

Equipped With:
128 Amp Power Supply
Cascade Tank Door


Machine Dimensions (LxWxH) 63" x 90.6"x 114"H
