Hyundai Wia L230A CNC Lathe (2017)

× Bidding has ended on this item.
Ended
LIVE WEBCAST

Programmable Tailstock, Parts Catcher, Chip Conveyor

Prev Lot
  Lot # 120
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Lubbock, TX
Logistics
LOADING FEE OF $1,850.00 WILL BE ADDED TO THE WINNING INVOICE.

  • Lot # 120
  • System ID # 1335336
  • Item # 1335337
Description

HYUNDAI WIA MODEL L230A CNC LATHE
S/N: G-1063-0499
NEW (4/2017)

MAX TURNING DIAMETER 13.98"
TOOL CAPACITY 13
RAPID TRAVEL SPEED (X/Z) 118 FT./MIN
Z-AXIS TRAVEL 17.32"
X-AXIS TRAVEL 8.66"
MAIN SPINDLE TORQUE 211.38 LB-FT.
MAIN SPINDLE OUTPUT 20 HP
SPINDLE SPEED 4000 RPM
DRIVE METHOD BELT
CHUCK SIZE 8" SEOAM 3 JAW
MAX TURNING LENGTH 17.32"
MAX TOOL SIZE 0.97"/1.57"


MACHINE EQUIPPED WITH:
FANUC i CNC CONTROL WITH: 10.4" LCD SCREEN
PARTS CATCHER
AUTOMATIC TOOL PRESETTER
SERVO PROGRAMMABLE TAILSTOCK
AMECO CHIP CONVEYOR
BAR FEED INTERFACE
(6) TOOLBLOCKS
CHUCK JAWS
 3/60/220V
168' L-R x 78" F-B x 86" H
