Hyundai Wia L230LMA with Live Tool (2017)

× Bidding has ended on this item.
Ended
LIVE WEBCAST

8" Seoam Hyd. 3 Jaw Chuck, All Tooling on Turret Including Live

  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Lubbock, TX
Logistics
Loading cost of $1,850.00 will be added to the winning invoice.

  • Lot # 117
  • System ID # 1335230
  • Item # 1335231
Description

HYUNDAI WIA MODEL L230LMA LIVE TOOL CNC LATHE
S/N: G1060-0166
New (7/2017)


CONTROL: FANUC i CNC CONTROL WITH 10.4" LCD SCREEN
CHUCK SIZE 8"
MAX SWING OVER BED 23.6"
MAX SWING OVER CARRIAGE 14"
MAX TURNING DIAMETER 12.2"
MAX TURNING LENGTH 20.5"
C-AXIS INDEX 0.001 DEG
SPINDLE NOSE A2-7
SPINDLE SPEED 4,000 RPM
SPINDLE POWER 20/15 HP
BAR CAPACITY 2.5"
RAPID TRAVERSE (X/Y) 118/118 FT/MIN
NUMBER OF TURRET STATIONS 12
DRIVEN TOOLS SPEED 5,000 RPM
TOOL CAPACITY 12

MACHINE EQUIPPED WITH

FANUC i CNC CONTROL WITH 10.4" LCD SCREEN
ALL TOOLING ON TURRET INCLUDING LIVE
8" SEOAM HYDRAULIC 3 JAW CHUCK
2.5" SPINDLE BORE
TOOL EYE
PARTS CATCHER
AUTOMATIC TOOL SETTER
SERVO PROGRAMMABLE TAILSTOCK
CHIP CONVEYOR
3/60/220V
182" L-R x 82" F-B x 88" H
